TRYBA High performance passive house Windows

Council member of China Passive Building Alliance

Green energy-saving doors and Windows

1.PRO PWV82M 7-chamber UPVC/Vinyl profile Passive house windows

Uw≤1.0 W/（㎡·K）

PRO PWV82M is based on the PWV70M system window, by optimizing the profile system and increasing the chamber to improve its thermal insulation performance. It is one of the best insulated windows in the world.The heat transfer Coefficient of the frame Uf≤0.8 W/（㎡·K）was obtained by increasing the insulated chambers and strength lining steel.

1
c0d57f2e4a4c2d0f9cb6978a7527c9c
  • The profile adopts high-performance PVC profile, the surface can be co-extruded or coated two processes, to achieve the appearance of diversity.
  • Section wall thickness ≥3.0 mm, exceed international a class requirement, welding angle strength can increase 15-20% , load bending and torsion strength can increase 10-12% .
  • Profile internal 7 cavity design and filled insulation materials, significantly improve the thermal insulation performance of the frame.
  • Standard European Standard Notch, suitable for all kinds of European standard hardware, can realize a variety of opening.
  • Special screw positioning design, so that the screw in the profile of the connection drawing force increased by 15-20% .
  • Special Welding Glue Bar to ensure the sealing performance of windows.
  • The maximum thickness of glass can be 45mm.
  • Renolit Film: The normal service life is more than 30 years outdoors.

Performance parameter：Uw≤0.8 W/（㎡·K）for passive house windows

2.T100 Low-Energy Aluminum Alloy Passive House Tilt and Turn Window

Engineered for ultra-high energy efficiency and superior performance, the T100 Tilt and Turn Window is designed to meet the stringent requirements of Passive House (Passivhaus) standards. Featuring a 100 Series thermal break aluminum alloy profile (6060-T6, 1.8mm wall thickness) with a 64mm PA66 GF25 thermal barrier, this window ensures exceptional thermal insulation, achieving a U-value of 0.79–1.0 W/(㎡·K)—ideal for minimizing heat loss in passive buildings.

100
1
  • Frame: "100 Series Thermal Break Aluminum Alloy Profile 6060-T6, Wall Thickness 1.8mm, 64mm PA66 GF25 Thermal Barrier."
  • Handle: "GU Base-Free Handle (Silver/Bronze/Black)."
  • Hardware: "GU Concealed 90-Degree Opening Hinge (100kg Load Capacity) + Restrictor Stay."
  • Hardware Upgrade: "Concealed 180-Degree Opening Hinge (80kg Load Capacity, Suitable for Door Leaf Width 500–1200mm, Height 560–1700mm)."
  • Standard Glass: "6G Low-E + 12A + 6G + 12A + 6G (Compatible with Glass Thicknesses: 24/30/31/34/40/42mm)."
  • Watertightness Performance: Class 6.
  • Air Permeability Performance: Class 8.
  • Wind Resistance Performance: Class 9.
  • Thermal Insulation Performance: 0.79–1.0 W/(㎡·K).
  • Sound Insulation Performance: 40dB–45dB.
  • Solar Heat Gain Coefficient (SHGC): 0.44

Performance parameter：SHGC-0.44 for passive house windows

3.H120 PASSIVE ALUMINUM-CLAD WOOD SYSTEM WINDOW

1750672977625
  • Thicken and strengthen wood thickness to improve the thermal insulation performance of the window frame, and use the Sikkens water-based paint imported from Germany, which does not contain formaldehyde.
  • And the water-based solvent can penetrate deeply into the wood grain.Effectively ensure that the window frame is not cracked, and the paint is not peeled off.
  • Four-way rubber strip sealing structure, good air tightness.
  • The glass is made of high-performance energy-saving glass. On the basis of ensuring the thermal insulation performance, the natural heat extraction performance and thermal insulation performance in winter are better.
  • The hardware adopts European general 13 series notch hardware, which is better to carry.
  • For passive construction house in non-cold areas.
  • Sound proofing level: 34dB

Performance parameters: Uw≤1.0 W/(㎡ K)

What is Renolit film?

It can be attached to the surface of PVC or aluminum alloy door and window frames.

1750674391051
1750674394642

① PMMA film

The unique SST solar thermal shielding technology reduces the influence of sunlight and heat on the profile surface, reduces the temperature of the profile, so as to ensure that the profile is not deformed even under strong light, and ensure the air tightness of the window.

② Printing ink

Rich color, texture realistic.

③PVC base

The exterior facade has strong resistance to color decay and does not fade or fall off.
Easy to clean, as clean as new.

④PUR adhesive bottom layer

The solidification process is irreversible, the solidification strength is high, and the water resistance is good

  • Surface materials imported from Germany;
  • Real wood grain styles can be selected to save precious wood resources by means of science and technology;
  • Surface weather resistance, acid resistance, aging resistance, corrosion resistance, wear resistance, pollution resistance easy to clean;
  • In the outdoor normal service life of more than 20 years;
  • SST solar thermal shielding technology, reduce the internal temperature of profiles;
  • 50μm polyacrylate, resist 99% uv, improve the uv resistance of profiles, prolong the service life, 12000 hours of aging resistance (xenon lamp) detection.
1750674845847

The normal service life is more than 20 years outdoors. Do not fade, do not fall off.

SST solar thermal shielding technology reduces the internal temperature of the profile. 50μm polyacrylate, resists 99% ultraviolet rays, improves the anti-ultraviolet ability of the profile, prolongs the service life, and is tested for 12,000 hours of aging resistance (xenon lamp).
The pigments selected for Renolit's film have good light resistance and are completely mixed into the raw materials. The color is bright and the pattern is realistic. The film with poor light resistance will yellow and fade in a short period of time. Good temperature resistance can ensure no edge opening and no degumming in the high temperature parts of the oven and stove. There is a layer of anti-scratch paint on the surface of Renolit film, which can be scratched with nails without leaving marks. It has good scratch resistance and stain resistance. Surface oil and dirt can be removed immediately with ordinary cleaners within 12 hours. No static electricity is generated in the middle, and it is not easy to adhere to dust.
